Main Pump Assy
| Model | Part No | Weight(KG) |
| S140-V | 2401-9236B | 85 |
| S225-V | 401-00356A | 128 |
| S290-V | 2401-9233B | 174 |
| S300-V | 401-00424C | 127 |
| S340-V | 400914-00245 | 146 |
| S420-V | 400914-00247 | 180 |
| S470-V | 400914-00248 | 180 |
| DX140LC | K1024107A | 141 |
| DX225 | 400914-00212 | 185 |
| DX300 | K1006550C | 127 |
| DX340 | 400914-00249 | 180 |
| DX420 | 400914-00251 | 180 |
| DX480 | 400914-00252 | 180 |
Main Control Valve
| Model | Part No | Weight(KG) |
| S140-V | 426-E0078B | 287 |
| S225-V | 410105-00054 | 193 |
| S290-V | 426-00066A | 171 |
| S300-V | 410105-00056 | 127 |
| S340-V | 410105-00069 | 211 |
| S420-V | 420-002818 | 424 |
| S470-V | 420-00280A | 489 |
| DX140LC | 420-00465B | 78 |
| DX225 | K1025391 | 203 |
| DX300 | 420-00519 | 203 |
| DX340 | K1002989A | 204 |
| DX420 | K1005095A | 418 |
| DX480 | K1005094A | 423 |
Reduction Gear and Motor Assy
| Model | Part No | Weight(KG) |
| S140-V | 404-00062 | 87 |
| S225-V | 130426-00004 | 170 |
| S290-V | 2101-1025K | 292 |
| S300-V | 130401-00021 | 294 |
| S340-V | 130426-00014 | 332 |
| S420-V | 130426-00015 | 355 |
| S470-V | 130426-00005A | 170 |
| DX140LC | K1007357B | 130 |
| DX225 | 130426-00011 | 174 |
| DX300 | 170301-00099 | 405 |
| DX340 | 130426-00014 | 332 |
| DX420 | 130426-00015 | 355 |
| DX480 | 130426-00005A | 170 |
| S140-V | 2401-9121B | 187 |
| S225-V | 401-00454C | 367 |
| S290-V | K1001992C | 403 |
| S300-V | K1001992C | 403 |
| S340-V | 170401-00027A | 380 |
| S420-V | 2401-6357 | 439 |
| S470-V | 2401-9229A | 370 |
| DX140LC | 170401-00029A | 158 |
| DX225 | 170401-00041A | 341 |
| DX300 | 170401-00048 | 406 |
| DX340 | 170401-00014A | 404 |
| DX420 | 2401-6257E | 439 |
| DX480 | 2401-9229A | 370 |
Arm, Boom, Bucket Cylinder Assy
| Model | Part No | Weight(KG) | Remarks |
| S140-5 | 2440-9230B | 104 | BOOM - LH |
| S225-V | 440-00355A | 167 | BOOM - LH |
| S290-V | 2440-9238B | 255 | BOOM - LH |
| S300-V | 440-00416B | 251 | BOOM - LH |
| S340-V | 2440-9279E | 281 | BOOM - LH |
| S420-V | 2440-9296C | 423 | BOOM - LH |
| S470-V | 440-00287A | 403 | BOOM - LH |
| DX140LC | K1026249 | 128 | BOOM - LH |
| DX225LC | 400309-00341 | 179.5 | BOOM - LH |
| DX300 | 440-00430A | 251 | BOOM - LH |
| DX340 | 400309-00084 | 313 | BOOM - LH |
| DX420 | K1003432 | 320 | BOOM - LH |
| DX480 | K1001341A | 402 | BOOM - LH |
| S140-5 | 2440-9231B | 157 | BOOM - RH |
| S225-V | 440-00356A | 166 | BOOM - RH |
| S290-V | 2440-9239B | 250.5 | BOOM - RH |
| S300-V | 440-00417B | 251 | BOOM - RH |
| S340-V | 2440-9278E | 281 | BOOM - RH |
| S420-V | 2440-9295C | 366 | BOOM - RH |
| S470-V | 440-00286A | 405 | BOOM - RH |
| DX140LC | K1026250 | 128 | BOOM - RH |
| DX225LC | 400309-00343 | 179.5 | BOOM - RH |
| DX300 | 440-00431A | 252 | BOOM - RH |
| DX340 | 400309-00085 | 400 | BOOM - RH |
| DX420 | K1003433 | 365 | BOOM - RH |
| DX480 | K1001340A | 402 | BOOM - RH |
| S140-5 | 440-00398A | 89 | BUCKET |
| S225-V | 440-00059A | 154 | BUCKET |
| S290-V | 400310-00065 | 240 | BUCKET |
| S300-V | 400310-00065 | 240 | BUCKET |
| S340-V | 400310-00025 | 270 | BUCKET |
| S420-V | 2440-9294H | 341 | BUCKET |
| S470-V | 440-00016E | 386 | BUCKET |
| DX140LC | 440-00411C | 107 | BUCKET |
| DX225LC | K1000884B | 187 | BUCKET |
| DX300 | 440-00433B | 218 | BUCKET |
| DX340 | 400310-00054 | 358 | BUCKET |
| DX420 | K1003483C | 341 | BUCKET |
| DX480 | K1014381A | 573 | BUCKET |
| S140-5 | 2440-9249A | 122 | ARM |
| S225-V | 2440-9236B | 244 | ARM |
| S290-V | 2440-9240G | 329 | ARM |
| S300-V | 400305-00064 | 331 | ARM |
| S340-V | 400305-00032 | 240 | ARM |
| S420-V | 440-00292A | 531 | ARM |
| S470-V | 440-00015B | 612 | ARM |
| DX140LC | K1024800A | 137 | ARM |
| DX225LC | K1044991A | 175 | ARM |
| DX300 | 440-00432E | 328 | ARM |
| DX340 | K1006192B | 680 | ARM |
| DX420 | K1003434E | 525 | ARM |
| DX480 | K1001344A | 627 | ARM |
| DX480 | K1001344A | 627 | ARM |
Arm, Boom, Bucket Cylinder Seal Kit
| Model | Part No | Part Name |
| DH05W | 2440-1034K | ARM CYLINDER SEAL KIT |
| DH05W | 2440-1036K | BOOM CYLINDER SEAL KIT |
| DH05W | 2440-1033K | BUCKET CYLINDER SEAL KIT |
| DH05W | 2440-1034K1 | ARM CYLINDER SEAL KIT |
| DH05W | 2440-1036K1 | BOOM CYLINDER SEAL KIT |
| DH05W | 2440-1033K1 | BUCKET CYLINDER SEAL KIT |
| DH05W | 2440-1034K2 | ARM CYLINDER SEAL KIT |
| DH05W | 2440-1036K2 | BOOM CYLINDER SEAL KIT |
| DH05W | 2440-1033K2 | BUCKET CYLINDER SEAL KIT |
| DH05W | 4177505K | ARM CYLINDER SEAL KIT |
| DH05W | 4177503K | BOOM CYLINDER SEAL KIT |
| DH05W | 4177502K | BUCKET CYLINDER SEAL KIT |
| DH07W | 2440-6081K | ARM CYLINDER SEAL KIT |
| DH07W | 2440-6083K | BOOM CYLINDER SEAL KIT |
| DH07W | 2440-6084K | BUCKET CYLINDER SEAL KIT |
| DH130LC | 2440-9036 | ARM CYLINDER SEAL KIT |
| DH130LC | 2440-9034 | BOOM CYLINDER SEAL KIT |
| DH130LC | 2440-9033 | BUCKET CYLINDER SEAL KIT |
| DH130LC-2 | 2440-6227 | ARM CYLINDER SEAL KIT |
| DH130LC-2 | 2440-6225 | BOOM CYLINDER SEAL KIT |
| DH130LC-2 | 2440-6228 | BUCKET CYLINDER SEAL KIT |
| DH200LC | 2440-6093 | ARM CYLINDER SEAL KIT |
| DH200LC | 2440-6091 | BOOM CYLINDER SEAL KIT |
| DH200LC | 2440-6094 | BUCKET CYLINDER SEAL KIT |
| DH220LC | 2440-9089 | ARM CYLINDER SEAL KIT |
| DH220LC | 2440-9087 | BOOM CYLINDER SEAL KIT |
| DH220LC | 2440-9090 | BUCKET CYLINDER SEAL KIT |
| DH220LC-3 | 2440-9146 | ARM CYLINDER SEAL KIT |
| DH220LC-3 | 2440-9144 | BOOM CYLINDER SEAL KIT |
| DH220LC-3 | 2440-9147 | BUCKET CYLINDER SEAL KIT |
| DH220LC-5 | 2440-9236 | ARM CYLINDER SEAL KIT |
| DH220LC-5 | 2440-9234 | BOOM CYLINDER SEAL KIT |
| DH220LC-5 | 2440-9237 | BUCKET CYLINDER SEAL KIT |
| DH280 | 2440-6122 | ARM CYLINDER SEAL KIT |
| DH280 | 2440-6120 | BOOM CYLINDER SEAL KIT |
| DH280 | 2440-6123 | BUCKET CYLINDER SEAL KIT |
| DH280-3 | 2440-9138 | ARM CYLINDER SEAL KIT |
| DH280-3 | 2440-9136 | BOOM CYLINDER SEAL KIT |
| DH280-3 | 2440-9139 | BUCKET CYLINDER SEAL KIT |
| DH280-5 | 2440-9240 | ARM CYLINDER SEAL KIT |
| DH280-5 | 2440-9238 | BOOM CYLINDER SEAL KIT |
| DH280-5 | 2440-9241 | BUCKET CYLINDER SEAL KIT |
| DH320 | 2440-9416 | ARM CYLINDER SEAL KIT |
| DH320 | 2440-9413 | BOOM CYLINDER SEAL KIT |
| DH320 | 2440-9415 | BUCKET CYLINDER SEAL KIT |
| DH320-3 | 2440-9416A | ARM CYLINDER SEAL KIT |
| DH320-3 | 2440-9413A | BOOM CYLINDER SEAL KIT |
| DH320-3 | 2440-9415A | BUCKET CYLINDER SEAL KIT |
| DH320-5 | 2440-9280B | ARM CYLINDER SEAL KIT |
| DH320-5 | 2440-9279B | BOOM CYLINDER SEAL KIT |
| DH320-5 | 2440-9281A | BUCKET CYLINDER SEAL KIT |
| DH400LC-3 | 2440-9440 | ARM CYLINDER SEAL KIT |
| DH400LC-3 | 2440-9438 | BOOM CYLINDER SEAL KIT |
| DH400LC-3 | 2440-9441 | BUCKET CYLINDER SEAL KIT |
| DH450 | 2440-9430 | ARM CYLINDER SEAL KIT |
| DH450 | 2440-9428 | BOOM CYLINDER SEAL KIT |
| DH450 | 2440-9428 | BUCKET CYLINDER SEAL KIT |
| MEGA200 | 4440-6265 | P/S CYLINDERSEAL KIT |
| MEGA200 | 4440-6268 | BUCKET CYLINDERSEAL KIT |
| MEGA300 | 4440-6217 | LIFT CYLINDERSEAL KIT |
| MEGA300 | 4440-6221 | P/S CYLINDERSEAL KIT |
| MEGA300 | 4440-6219 | BUCKET CYLINDERSEAL KIT |
| MEGA400 | 4440-6207 | LIFT CYLINDERSEAL KIT |
| MEGA400 | 4440-6211 | P/S CYLINDERSEAL KIT |
| MEGA400 | 4440-6209 | BUCKET CYLINDERSEAL KIT |
| S320LC / S330LC-3 | 2440-9416AKT | ARM CYLINDER SEAL KIT |
| S320LC / S330LC-3 | 2440-9413AKT | BOOM CYLINDER SEAL KIT |
| S320LC / S330LC-3 | 2440-9415AKT | BUCKET CYLINDER SEAL KIT |
| S220LC-V | 2440-9236KT | ARM CYLINDER SEAL KIT |
| S220LC-V | 2440-9234KT | BOOM CYLINDER SEAL KIT |
| S220LC-V | 2440-9339KT | BUCKET CYLINDER SEAL KIT |
| S280LC | 2440-6122KT | ARM CYLINDER SEAL KIT |
| S280LC | 2440-6120KT | BOOM CYLINDER SEAL KIT |
| S280LC | 2440-6123KT | BUCKET CYLINDER SEAL KIT |
| S290LC-V / S300LC-V | 2440-9240KT | ARM CYLINDER SEAL KIT |
| S290LC-V / S300LC-V | 2440-9238KT | BOOM CYLINDER SEAL KIT |
| S290LC-V / S300LC-V | 2440-9241KT | BUCKET CYLINDER SEAL KIT |
| S330LC-V / S360LC-V | 2440-9280CKT | ARM CYLINDER SEAL KIT |
| S330LC-V / S360LC-V | 2440-9281AKT | BOOM CYLINDER SEAL KIT |
| S330LC-V / S360LC-V | 2440-9281AKT | BUCKET CYLINDER SEAL KIT |
Pump Parts
| Machine Model | Pump Model | Part Number | Part Name | Unit |
| S130W-3 | A8V86 | 110007029 | Cylinder Block | PC |
| 110020726 / 279 | Valve Plate | PC | ||
| 1100051985 | Piston Ring Ass'y | SET | ||
| 1100203746 | Ring of Piston | PC | ||
| 1700628477 | Set Plate | PC | ||
| 1100072625 | Center Pin | PC | ||
| 1100051958 | Disc Spring | PC | ||
| S200W | A8V0107 A8VO107 |
087-4783 | Cylinder Block | PC |
| 099-5858/65 | Valve Plate(F,R) | PC | ||
| 099-5713A | Piston Ring Ass'y | SET | ||
| 9T-3475 | Ring | PC | ||
| 105-1516 | Set Plate | PC | ||
| 9T-3369 | Center Pin | PC | ||
| 9T-3368 | Disc Spring | PC | ||
| S170LC/W-3 S200W-3 S280 |
A8V115ESBR | 1100218931 | CylInder Block | PC |
| 1100029117 (126) | Valve Plate(L,R) | PC | ||
| 1100218922 | Piston Ring Ass'y | SET | ||
| Ring of Piston | PC | |||
| 1700625744 | Set Plate | PC | ||
| 1100037439 | Center Pin | PC | ||
| 1100038579 | Disc Spring | PC | ||
| S80W-3 | A10V43 | Cylinder Block | PC | |
| Valve Plate(F,R) | PC | |||
| Piston Shoe Ass'y | SET | |||
| Set Plate | PC | |||
| Ball Guide | PC | |||
| Shoe Plate | PC | |||
| S450(OLD) | HPR100 | 234.320.08.05 | Cylinder Block | PC |
| 254.324.02.01 / 05 | Valve Plate(L,R) | SET | ||
| 234.320.04.25 | Piston Shoe Ass'y | SET | ||
| 234.320.14.00 | Set Plate | PC | ||
| 234.320.14.00 | Ball Guide | PC | ||
| 254.323.20.15 | Swash Plate | PC | ||
| S320 S320(OLD) |
HPR130 Double |
256.320.08.05 / 02.06 | Cyl Block+V/V Plate | SET |
| 256.320.04.05 | Piston Shoe Ass'y | SET | ||
| 256.320.14.00 | Set Plate | PC | ||
| 256.320.14.00 | Ball Guide | PC | ||
| 273.323.01 / 05 | Drive Shaft | PC | ||
| DH10 | HPV125A | 9039894 | Cylinder Block | PC |
| 3018520 | Valve Plate | PC | ||
| 9039895 | Piston Ass'y | SET | ||
| 4061020 | Square Bearing | PC | ||
| DH08 | HPV125B | 2013674 | Cylinder Block | PC |
| 9044928 (9037763) | Piston Ass'y | SET | ||
| 2016517 | Head Valve | PC | ||
| 3020028 | Center Joint Rod | PC | ||
| 4061020 | Square Bearing | PC | ||
| S320(NEW) S330-3 S400LC |
K3V180DT | 2953802226 / 27 | Cyl Block+V/V Plate | SET |
| HE4D00574 | Piston Shoe Ass'y | SET | ||
| 53801840 | Ball Guide | PC | ||
| 43800488 | Set Plate | PC | ||
| 51001536B | Shoe plate | PC | ||
| 718422 | Swash Plate | PC | ||
| HE4E00603 | Spacer | PC | ||
| HE4D00691 / 2 | Shaft(F,R) | PC | ||
| HE4E00596 | Spring | PC | ||
| S280(NEW) S280LC-3 |
K3V140DT | 704527-PH/29-PH | Cyl Block+V/V Plate | SET |
| HE2D00304 | Piston Shoe Ass'y | SET | ||
| 2953801840 | Ball Guide | PC | ||
| 294380488 | Set Plate | PC | ||
| 51001536B | Shoe plate | PC | ||
| 2923800908 | Swash Plate | PC | ||
| 2953801841 | Spacer | PC | ||
| 2933800890C / 903 | Shaft(F,R) | PC | ||
| 2953801842 | Spring | PC | ||
| S220LC/-3 | K3V112DT | 716776-PH/7-PH | Cyl Block+V/V Plate | SET |
| HE2D00298 | Piston Shoe Ass'y | SET | ||
| 2943801765 | Ball Guide | PC | ||
| 2943800463 | Set Plate | PC | ||
| 295388003B | Shoe plate | PC | ||
| 2953801990 | Swash Plate | PC | ||
| 2953801764 | Spacer | PC | ||
| 2933800774C / 883B | Shaft(F,R) | PC | ||
| 2953801769 | Spring | PC | ||
| S120W S130/NEW/W/-2 |
K3V63DT | 43800428BA | Cyl Block + V/V Plate | SET |
| 704203A | Piston Shoe Ass'y | SET | ||
| 43800424A | Set Plate | PC | ||
| 53801625 | Ball Guide | PC | ||
| 538001742A | Shoe Plate | PC | ||
| 3800732 | Swash Plate | PC | ||
| 43800426H | Shaft(F) | PC | ||
| 33800889D | Shaft(R) | PC | ||
| 53801624 | Spacer | PC | ||
| 53801623 | Spring | PC | ||
| DH10L S280(OLD) |
NV137DT | G35101418 | Cyl Block+V/V Plate | SET |
| G35101419 | Piston Shoe Ass'y | SET | ||
| G35100241 | Ball Guide | PC | ||
| G35100241 | Set Plate | PC | ||
| G55100259 | Swash Plate | PC | ||
| G55100211 | Shaft(F) | PC | ||
| 38100-113G | Shaft(R) | PC | ||
| 38A00-157 | Spring | PC | ||
| DH07S S200LC |
NV111DT | 38900-12-141A | Cyl Block+V/V Plate | SET |
| 38901-151 | Piston Shoe Ass'y | SET | ||
| 38800-156 | Ball Guide | PC | ||
| 38800-153A | Set Plate | PC | ||
| 3880RA36 | Swash Plate | PC | ||
| 388020-11G | Shaft(F) | PC | ||
| 38G20-113 | Shaft(R) | PC | ||
| 38800-157 | Spring | PC | ||
| DH07W | NV84DT | 00263003A | Cyl + V/V Plate(F,R) | SET |
| 0263001A | Piston Shoe Ass'y | SET | ||
| 0263004 | Set Plate | PC | ||
| 0263004 | Shoe plate | PC | ||
| 0263005 | Swash Plate | PC | ||
| DH110 DH130 |
NV64DT | 38500-12-141A | Cyl Block+V/V Plate | SET |
| 38501-151 | Piston Shoe Ass'y | SET | ||
| 38500-156 | Ball Guide | PC | ||
| 38E00-153 | Set Plate | PC | ||
| 3850R-251 | Swash Plate(Single) | PC | ||
| 38E0M-212 | Swash Plate(Double) | PC | ||
| 38521-111 | Shaft(R) | PC | ||
| 38500-157 | Spring | SET | ||
| DH07-3 S280N |
KVC925 | 4070145 | Cylinder Block | PC |
| 0126212 | Valve Plate | PC | ||
| 0126205A | Piston Shoe Ass'y | SET | ||
| 0100010 | Set Plate | PC | ||
| 0100014 | Shoe plate | PC | ||
| 0126207 | Swash Plate Ass'y | PC | ||
| 0126206 | Fix Plate | PC | ||
| DH16 | KVC932 | 0237801 | Cylinder Block | PC |
| 0237813 | Valve Plate | PC | ||
| 0241405 | Piston Shoe Ass'y | SET | ||
| 0232311 | Set Plate | PC | ||
| 0237821 | Shoe plate | PC | ||
| 0237802 | Swash Plate | PC | ||
| S80W | NVK45DT | 38400-141A | Cylinder Block | PC |
| 38401-11-151A | Piston Shoe Ass'y | SET | ||
| 3840R-313 | Valve Plate(F,R) | PC | ||
| 38400-18-153 | Set Plate | PC | ||
| 38400-18-156 | Ball Guide | PC | ||
| 38400-211 | Shoe Plate | PC | ||
| 38420-111G | Drive Shaft | PC |
Swing Motor Parts
| Machine Model | Motor Model | Part Number | Part Name | Unit |
| S130LC S130W S130W-2 |
M2X63 | 3733700472 | Cylinder Block | PC |
| 3743700472 | Valve Plate | PC | ||
| 3753700507 | Piston Shoe Ass'y | SET | ||
| 3743700471 | Set Plate | PC | ||
| 3753700501 | Ball Guide | PC | ||
| 3753700499 | Shoe Plate | PC | ||
| 3733700471 | Drive Shaft | PC | ||
| 3743700426 | Plate Friction | PC | ||
| 3743700435 | Plate Steel | PC | ||
| S220LC-5 | M2X120 | 0425104 | Cylinder Block | PC |
| 0425112 | Valve Plate | PC | ||
| 0425101 | Piston Shoe Ass'y | SET | ||
| 0425110 | Set Plate | PC | ||
| 0425105 | Ball Guide | PC | ||
| 0425111 | Shoe Plate | PC | ||
| 0425103 | Drive Shaft | PC | ||
| 0425119 | Friction Plate | PC | ||
| 0425120 | Separation Plate | PC | ||
| S220LC-3 S280 S280LC-3 S290LC-5 |
M2X150/170 | 3733700449 | Cylinder Block | PC |
| 3733700553 | Valve Plate | PC | ||
| HE4A00291 | Piston Shoe Ass'y | SET | ||
| 3753700454 | Ball Guide | PC | ||
| 3743700406 | Set Plate | PC | ||
| 3753700492 | Shoe Plate | PC | ||
| 3733700398 | Drive Shaft | PC | ||
| 3743700486 | Plate Friction | PC | ||
| 3743700415 | Plate Steel | PC | ||
| DH130(OLD) | MX173 | 03083820/380-1 | Cyl Block+V/V Plate | PC |
| 308601 | Piston Shoe Ass'y | SET | ||
| 0308603 | Set Plate | PC | ||
| 0308603 | Ball Guide | PC | ||
| 0308613 | Shoe Plate | PC | ||
| 0308628 | Drive Shaft | PC | ||
| S170/W-3 S210-1/-2 |
SG08E | 1318-168 | Cylinder Block | PC |
| 1313-171 | Valve Plate | PC | ||
| 1321-122 | Piston Shoe Ass'y | SET | ||
| 1398-150 | Set Plate | PC | ||
| 1398-149 | Shoe Plate | PC | ||
| DH07S DH08 |
HTM450 | 4166993C | Cylinder Block | PC |
| 0212108 | Valve Plate | PC | ||
| 4166993P | Piston Shoe Ass'y | SET | ||
| 0166334 | Fix Plate | PC | ||
| 0166636 | Set Plate | PC | ||
| 0166608 | Shoe Plate | PC |
The brand names such as Hyundai, Doosan, Volvo, Cat, Caterpillar, Case, John Deere, Komatsu, Hitachi, JCB, Atlac Copco, Sandvik, Tamrock, Furukawa, Toyo, Ingersoll Rand, or any others are registered trademarks of the respective original manufacturers. All names, descriptions, numbers and symbols are used for reference purposes only.
